1. High quality material and first-class technology
2. Powerful function, continuously variable transmission
3. Regular appearance, small and beautiful
4. Convenient operation and intuitive digital display
Specification
|
VFD type |
HZ800SF |
HZ300A |
HZ800 |
|
Drive control mode |
VF/ Current closed loop Vector/velocity closed loop vector |
VF/ Current closed loop vector |
VF/ Current closed loop Vector/velocity closed loop vector |
|
Same power Starting torquecomparison |
★★★★★ |
★★★★ |
★★★★★ |
|
Torque control |
√ |
√ |
√ |
|
Shell color |
Brown |
Black |
Black |
|
Power range |
Three-phase 380V: 0.75 kw ~ 110 kw |
Single-phase 220V: 0.4 kw ~ 75 kw Three-phase 380V: 0.75 kw ~710 kw |
Single-phase 220V: 0.4 kw ~ 75 kw Three-phase 380V: 0.75 kw ~710 kw |
|
Operating keyboard |
Dual row display/LCD Shuttle potentiometer |
Single row display Adjustable potentiometer |
Single row display Adjustable potentiometer |
|
Synchronization rate volume |
★★★ |
★★★★ |
★★★★ |
|
Multifunction input Number of terminals |
8 |
8 |
8 |
|
Analog quantity Input quantity |
2 |
2 |
2 |
|
Analog quantity Output quantity |
2 |
2 |
2 |
|
Relay Output quantity |
2 |
2 |
2 |
|
485 communication |
√ |
√ |
√ |
|
Module/single tube |
Module |
Module |
Module |
|
An external expansion card is connected |
X |
X |
Support expansion card (PG/IO) |
Application
(1) AC motor speed regulation can be realized by frequency converter. As the frequency converter can be regarded as an AC power supply with adjustable frequency, for the existing motor running at constant speed, as long as the frequency converter and the corresponding equipment are connected between the power supply and the motor, the motor speed control can be realized, without the need to transform the motor and the system.
(2) with a wide range of speed and high speed accuracy. The speed range of general purpose frequency converter can reach more than 1:10, and the speed range of high-performance vector frequency converter can reach 1:1000. Moreover, the output torque of the motor can be controlled when the frequency converter with vector control mode is used for speed control of the asynchronous motor.
(3) It can reduce the starting current of the motor. When the motor frequency power supply is started directly, the starting current is 4 to 7 times the rated current. This current will greatly increase the electrical stress of the motor winding and generate heat, thus reducing the service life of the motor. When the frequency converter adjusts the speed, it can start from zero speed and zero voltage and accelerate according to the law of slope function, thus limiting the starting current of the motor.
(4) Can achieve high speed, high voltage, high current control. At present, the output frequency of the high-frequency frequency converter can reach 300OKHz. When the two-pole asynchronous motor is driven by this high-speed frequency converter, a high speed of 180000 RPM can be obtained. With the continuous development of frequency conversion technology, the output frequency of high frequency converter is also improving. High speed drive is also an important advantage of frequency converter speed control.
Pictures
FAQ
Q: Do you supply pattern ? Is it free?
A: If the pattern is low value, we will grant the free pattern with freight collect. But for some excessive fee samples, we want to gather the pattern charge.
Q: What is your time period of payment?
A: 30% down charge earlier than producing and 70% stability charge earlier than shipping.
